Therapy TECAR - TECNOSIX TCR150

TECNOSIX TCR150 is an innovative complete diathermy equipment with infinite therapeutic possibilities; it is capable of providing practitioners with an easy and intuitive treatment. It is a valuable tool for professionals in the healthcare, sports, medical, and rehabilitation fields.

TECNOSIX TCR150 allows for non-invasive capacitive and resistive diathermic treatment, which is capable of generating, with the highest efficiency and without pain, endogenous hyperemia and stimulating blood circulation in all different cellular layers up to lymphatic drainage. Diathermic treatment has an anti-inflammatory effect resulting in both improved blood circulation and a significant reduction in pain.

This stimulates a natural and physiological reaction of the body, depending on the specific pathology, while simultaneously accelerating the healing process. Due to special applicators, it is capable of delivering the right amount of energy to the involved cellular layers. In TECNOSIX TCR150, the energy absorbed by the patient is controlled by reading a visible impedance audiometer by the practitioner and a series of data that modulates the current consumption. Impedance is a measure of a body's ability to allow the passage of electric current; low impedance means good conduction, high impedance means the exact opposite.

TECNOSIX TCR150 reads all changes in the electrical impedance of the tissue in real-time. This not only makes it a tissue investigation tool to correct the working method but also makes treatments more effective by improving results and application time.

Characteristics:

Transmission frequencies: 0.5 MHz (+0 - 15% typically 448 kHz) / 1.0 MHz (+0 - 20% typically 0.8 MHz)

• Medical power supply: 300 W

• Maximum power: 150 W

• Maximum power consumption: 300 VA

• Power supply 90-240 Vac / 50-60 Hz

• Medical device class: II b

• Dimensions in mm: 170 x 315 x 390

• Weight: approximately 5 kg

MANUAL RESISTIVE CAPACITIVE MODE • Ergonomic handle with 3 working configurations • Total and instantaneous absorbed energy reader • Continuous-pulsed emission

AUTOMATIC DYNAMIC MODE • Double grip for adhesive plates, allowing practitioners to associate treatment with functional work • Pulsed emission for thermal effect control

BIPOLAR MODE Bipolar resistive handle, which allows the use of the classic mode without using the return plate

PRECONFIGURED PROTOCOLS PERSONALIZED PROGRAMS

UNIQUE RESISTIVE CAPACITIVE HANDLE with three working angles and interchangeable heads.

BIPOLAR HANDLE

which allows you to work without inserting the return plate (as it is included in the handle itself). Thanks to this handle, it is possible to work on small and awkward anatomical surfaces.

Supplied with:

• 1 treatment cream
• 2 clamps and 50 adhesive plates (25 small and 25 large) for automatic treatment
• 1 straight capacitive/resistive handle

Available on request:

• Transport cart
• 1 straight capacitive/resistive handle with 3 working angles
• Bipolar handle
• Wheel cart with support for handle
